Structural Load Calculator (2026) – Slab, Beam & Column Master
Expert Guide
Professional dead and live load estimator for RCC slabs, beams, and columns per IS 875.
⚡ Quick Answer
For a 150mm RCC slab: Dead Load = 0.15m × 25 kN/m³ = 3.75 kN/m². For full structural analysis, visit pro.nirmansutra.com.
🛠️ How It Works
- •Select the structural component (Slab, Beam, or Column) to calculate gravity loads.
- •Enter the geometric dimensions and standard loading assumptions.
- •The tool applies IS 875 dead load constants (Grade 25 concrete) for automatic self-weight calculation.
- •Observe the Factored Load results prepared for direct structural member sizing.
📐 Calculation Formula
RCC Slab DL = Thickness × 25 kN/m³
Beam UDL = (Width × Depth) × 25 + Wall Weight
Factored Load = Total Load × 1.5 (Safety Factor)
📋 Real-Life Example
Example: RCC Column with 20m² tributary area, 3 floors, avg load 12 kN/m²:
1. Floor Load = 12 kN/m².
2. Per floor per columns = 12 × 20 = 240 kN.
3. Total (3 floors) = 720 kN.
4. Column size hint = 300mm × 300mm for this range.
⚠️ Common Mistakes to Avoid
- ✕Forgetting the 1.5 Load Factor — structural design requires a safety multiplier for unforeseen live loads.
- ✕Ignoring floor finish — 1kN/m² of tiles/screed adds 25% extra weight to a typical 125mm slab.
- ✕Using nominal wall weights — 230mm brick walls with plaster weigh significantly more than often assumed (typically 12kN/m for 3m height).
🔍People Also Search / यो Calculator मा अक्सर खोजिने कुराहरू
RCC slab dead load calculator IS 875 standards
Beam UDL calculation for brick wall load guide
Axial load carrying capacity of column formula RCC
Live load for residential vs commercial buildings chart
Pillar ra beam ko load ganana garne tarika
Beam par diwar ka load kaise nikale
Seismic weight calculation of structural members Nepal
Slab thickess vs self weight calculation guide
Factored load vs Service load differences IS 456
बीम पर दीवार का लोड कैसे निकालें?
❓ Frequently Asked Questions
Dead Load = Thickness × Density. For a standard 150mm RCC slab, it is 0.15m × 25 kN/m³ = 3.75 kN/m².
Total Column Load = (Tributary Area × Floor Load × No. of Floors) × 1.5. This accounts for both dead and live loads with a safety factor.
This is the "Partial Safety Factor for Loads" mandated by IS 456 to account for unforeseen loading and material variability.
