Rebar Detailing Calculator (2026) – Cutting Length & Stirrups

Expert Guide
Babu

Get millimetre-perfect cutting lengths for reinforcement bars and stirrups. See Rebar Master for simple weight estimation.

Detailing of steel stirrups and ties at a column-beam junction

⚡ Quick Answer

Cutting length must always subtract concrete cover and bend deductions. A 4m beam with 25mm cover and 9d hooks needs a 4.16m cut piece.

🛠️ How It Works

📐 Calculation Formula

Cutting Length = L - 2(Cover) + Hooks - Bend Deductions
Bend Deduction = 2d (90°), 3d (135°)
Rebar Detailing & Hook Bending Diagram

🔗Related Calculators

Most Used
🔩

Rebar Master

⚡ Precise TMT estimation

Calculate TMT bar weight (kg/tonne), running length, and number of bars by spacing. Standard D²/162.2 density support.

Calculate Steel
Try Now →
📋

BBS Calculator

⚡ Pre-construction BBS

A comprehensive tool for calculating the Bar Bending Schedule before bending and cutting starts.

Generate BBS
Try Now →

⚠️ Common Mistakes to Avoid

  • ✕Forgetting to subtract concrete cover from ALL sides of a stirrup.
  • ✕Using 10mm stirrups without checking if 8mm is sufficient — this increases steel cost by 50% for ties.

🔍People Also Search / यो Calculator मा अक्सर खोजिने कुराहरू

Stirrup cutting length formula for 9x12 beam Nepal
Rebar detailing hooks and cranks standard guide
Beam and Column tie spacing calculator online
Bend deduction chart for TMT bars 90 vs 135
Ring banaune formula ra dandiko hisab
Column ki ring ka sariya kaise nikale
Reinforcement detailing for earthquake zones Nepal
Crank bar cutting length formula for slabs
Overlapping vs Welded rebar joint cost
कॉलम की रिंग का सरिया कैसे निकालें?

❓ Frequently Asked Questions

Cutting Length = Perimeter of Ring + (2 × Hook Length) - (Total Bend Deductions). Use 10d for 135-degree seismic hooks.
When rebar is bent 90°, it elongates. Subtract 2 × Diameter (2d) for every 90° bend to get the actual cutting length.
Seismic codes (IS 13920) mandate 135° hooks to prevent stirrups from opening during earthquakes, providing better core confinement.
