Structural Load & Safety Calculator (Nepal Engineering)

Expert Guide

Estimate gravity loads on concrete slabs.

Architect showing house blueprint at construction site

⚡ Quick Answer

The total design load on an RCC slab is the sum of its dead load (self weight + floor finish) and live load, multiplied by a safety factor (1.5 as per IS:456).

🛠️ How It Works

Self Weight = (Thickness/1000) × 25 kN/m³. Total Factored Load = 1.5 × (Dead Load + Live Load). Now calculate beam transfers here → Beam Load Calculator

Enter the slab thickness in mm to calculate self-weight.
Add the expected floor finish load (typically 1-1.5 kN/m²).
Input the live load based on usage (e.g., 2 kN/m² for residential).
The tool calculates the total factored load for structural safety checks.

📐 Calculation Formula

Dead Load = (T/1000 × 25) + FF

Factored = 1.5 × (DL + LL)

📋 Real-Life Example

150mm slab, 1.0 finish, 2.0 live load:
• Self Weight = 0.15 × 25 = 3.75
• Dead Load = 3.75 + 1.0 = 4.75
• Factored = 1.5 × (4.75 + 2.0) ≈ 10.1 kN/m²

⚠️ Common Mistakes to Avoid

Not including the weight of partition walls on the slab. Most people forget this → Wall & Slab Transfer Load
Underestimating the live load for public corridors or commercial spaces.
Ignoring the weight of heavy waterproofing layers on roof slabs.

❓ Frequently Asked Questions

What is the density of RCC?

Standard reinforced concrete density is taken as 25 kN/m³ (approx 2500 kg/m³) according to IS 875 Part 1.
