Concrete Raw Materials & Mix Estimator (Nepal Standards)
Expert Guide

Enter your total concrete volume and the specific mix ratio (Cement : Sand : Aggregate) to find the exact quantity of each material needed.

⚡ Quick Answer
A concrete mix ratio (like 1:1.5:3 for M20) defines the volumetric proportions of Cement, Sand, and Coarse Aggregate. To find material quantities, multiply your wet concrete volume by 1.54 to find the total dry volume required before mixing.
🛠️ How It Works
The concrete mix ratio (C:S:A) determines the strength grade. Multiply the wet volume by 1.54 to get the dry volume, then divide by the sum of parts. Standard M20 (1:1.5:3) has a sum of 5.5 parts. Now calculate it here → Cement Bags Calculator
- Enter the target wet volume of concrete you need to cast.
- Select a standard Mix Grade (e.g., M20 for structural) or enter a custom ratio.
- The engine automatically applies the 1.54 dry shrinkage factor.
- It divides the total dry volume into individual components: Cement, Sand, and Aggregate.
- Cement is converted from volume (m³) to standard 50kg bags using 0.0347 m³ per bag.
📐 Calculation Formula
Dry Volume = Wet Volume × 1.54
Cement (m³) = Dry Volume × (C / C+S+A)
Cement (Bags) = Cement (m³) / 0.0347
📋 Real-Life Example
For 10 m³ of M20 (1:1.5:3) concrete: • Dry Volume = 10 × 1.54 = 15.4 m³ • Sum of parts = 5.5 • Cement Volume = 15.4 / 5.5 = 2.8 m³ • Cement Bags = 2.8 / 0.0347 = 81 bags
⚠️ Common Mistakes to Avoid
- Assuming 1m³ of wet concrete requires 1m³ of dry ingredients. You actually need 1.54m³ of dry mix → Dry Volume Calculator
- Using a weak M15 mix for critical members like columns or suspended slabs.
- Not adjusting for moisture in the sand (bulking), which can affect the final volume and strength.
- Adding too much water, which reduces the compressive strength of the concrete significantly.
❓ Frequently Asked Questions
It is the total of all proportion values. For M20 (1:1.5:3), the sum is 1 + 1.5 + 3 = 5.5. For M15 (1:2:4), the sum is 7.
When sand, aggregate, and cement are dry, they have air voids. When water is added, these gaps are filled, causing the total volume to shrink by approx 35%. 1.54 is the standard factor to compensate for this.
In Nepal, M25 (1:1:2) or higher is often recommended for columns, while M20 (1:1.5:3) is the standard for slabs.
If using a 1:2:4 mix, one 50kg bag (approx 1.25 cu ft) would require 2.5 cu ft of sand and 5 cu ft of aggregate.
